Maximum power for static 3D print systems
The LUXBEAM® Rapid System LRS-WQ SL AC is a DLP®-based stereolithography subsystem specifically designed for professional 3D printing and additive prototyping/manufacturing systems.
Recommended use
Superior resolution light engine
– ideal for static use in 3D printing
LRS-WQ DL LC Single LED Air Cooled
Configurable with numerous imaging lenses at different magnifications, the system provides from 1,9-micron native pixel pitch – up to 130 microns in image, corresponding to an A4-sized build area.
Configurations are compatible with the other versions in optics, mechanics, and electronics software implementations through a robust network ethernet interface for system control and monitoring.
Empowering professional 3D printing systems
Based on the robust and reliable high-resolution DLP9000 WQXGA chip, the LRS-WQ series ensures lifetime durability with low maintenance costs. While the entry-level version is air-cooled, the top-performing versions come with liquid cooling – which is particularly beneficial in certain applications requiring maximum stability. Liquid cooling further stabilizes the LED light source, allowing it to perform at even higher power, making the LUXBEAM® LRS-WQ DL LC the most powerful UV LED projection module available.
Long-lasting performance
The LRS-WQ light engine series is a robust, proven, and reliable plug-and-play module system. With an integrated CPU and industry-standard ethernet communication interface, the light engines provide advanced internal communication, status monitoring communication, status tracking, and other logging features.
Compact design
As the most compact projector in its class, the LRS-WQ light engine enables machine builders to achieve space-saving machine footprints.
Specifically designed for professional 3D printing and static additive manufacturing and prototyping systems, the LRS-WQ series consists of three product versions. Each version offers unique beneficial features in terms of power, ranging from 4 W to a massive 12.5 W for the Dual LED Liquid Cooled version. All share the same compact cabinet size, allowing easy swapping.
